Bilstein AS3 Series shock absorbers are developed to deliver superior damping characteristics with virtually no rod pressure build-up. Based on Bilstein’s race-proven 46mm monotube design, the AS3’s unique piggyback nitrogen chamber delivers a fade-free performance without the gas pressure buildup that’s common in conventional shock designs. The aluminum threaded body modular assembly with single adjustable shaft tuning is purchased as a dry kit with pistons, piston bands and heims sold separately. The AS3 Series shock absorber offers consistent grip and optimal traction.
- Bilstein AS3 Series shock absorbers are developed to deliver superior damping characteristics with virtually no rod pressure build-up.
- Based on Bilstein’s race-proven 46mm monotube design, the AS3’s unique piggyback nitrogen chamber delivers a fade-free performance without the gas pressure buildup that’s common in conventional shock designs.
- The aluminum threaded body modular assembly with single adjustable shaft tuning is purchased as a dry kit with pistons, piston bands and heims sold separately.
Attributes:
- Brand Name: Bilstein
- GTIN: 00651860916200
- Adjustable Damping: Single Adjustable - Rebound
- Body Design: Threaded Body Screw Top (Coilover)
- Body Diameter (ID): 46mm
- Body Material: Aluminum
- Collapsed Length (IN): 17.58
- Collapsed Length (MM): 446.5
- Extended Length (IN): 22.83
- Extended Length (MM): 580
- Finish: Clear Anodized
- Internal Design: Monotube
- Lower Mount Type: 1/2in Heim
- PartType: Shocks / Struts
- Piston Type: Sold Separately
- Segment: Motorsports
- Series: AS3 Series
- Spring Hardware: E4-MSG-0096A00
- Spring Seat Included: Yes
- Upper Mount Type: 1/2in Heim
- Valving Identifier: Dry Kit (no valving)
Extended Information:
- Country of Origin: US
- Emissions : CARB Eligible
- Life Cycle Status: Available To Order
Packing Information:
- Quantity of Each: 1.0
- Package UOM: EA
- Dimension: 26.7500 x 6.1000 x 6.1000 inches
- Weight: 7.0000 lb
